Hikvision 16 Channel Acusense 4K NVR with POE

Hikvision DS-7616NXI-K2/16P 16-Channel PoE AcuSense 4K NVR

The Hikvision DS-7616NXI-K2/16P is a professional 16-channel network video recorder designed for high-performance IP CCTV systems. With built-in PoE ports, intelligent AcuSense technology, 4K video output, and efficient video compression, this NVR is ideal for homes, offices, retail stores, warehouses, commercial premises, and larger security installations.

Equipped with 16 independent PoE network interfaces, the DS-7616NXI-K2/16P allows compatible IP cameras to be connected directly to the NVR using a single network cable per camera for both power and data. This simplifies installation, reduces cable clutter, and makes the unit a practical plug-and-play recording solution for professional CCTV setups.

Hikvision AcuSense technology helps improve security monitoring by using human and vehicle target classification to reduce false alarms caused by irrelevant movement such as animals, rain, leaves, shadows, or lighting changes. AcuSearch support also helps make event playback more efficient by allowing faster searching of relevant footage when used with compatible cameras.

With support for H.265+ video compression, the NVR helps reduce storage requirements while maintaining good video quality. Its 2 SATA interfaces support large-capacity hard drives, making it suitable for continuous recording, long footage retention, and multi-camera surveillance systems.

Key Features

• 16-channel IP camera input

• 16 built-in PoE ports for plug-and-play camera connection

• Hikvision AcuSense technology

• Human and vehicle target classification

• AcuSearch technology for efficient playback

• Accurate perimeter protection to help reduce false alarms

• H.265+ / H.265 / H.264+ / H.264 video compression

• Up to 160Mbps incoming bandwidth

• Up to 160Mbps outgoing bandwidth

• HDMI and VGA independent video output

• HDMI output up to 4K resolution

• Supports high-resolution IP camera recording

• Up to 16-channel synchronous playback

• 2 SATA interfaces for HDD installation

• Up to 16TB capacity per HDD, model/firmware dependent

• 1 × RJ45 Gigabit LAN interface

• 16 × RJ45 10/100Mbps PoE interfaces

• PoE standard: IEEE 802.3af/at

• 4 alarm inputs and 1 alarm output

• USB ports for backup and mouse control

• Two-way audio support

• ONVIF support for compatible third-party IP cameras

Ideal For

• Home CCTV systems

• Office surveillance

• Retail stores and shopping areas

• Warehouses and factories

• Schools and commercial buildings

• Multi-camera IP CCTV installations

• Perimeter protection systems

• Upgrading from analogue CCTV to IP cameras

• Installations needing built-in PoE and smart event filtering

Why Choose the Hikvision DS-7616NXI-K2/16P?

The DS-7616NXI-K2/16P is a strong choice for users who need a reliable, intelligent, and expandable NVR for up to 16 IP cameras. Its built-in PoE ports make installation easier, while AcuSense technology helps reduce nuisance alerts and makes security monitoring more accurate. Combined with 4K output, efficient compression, large HDD support, and smart playback tools, it provides a complete recording platform for modern CCTV installations.

Installation Note

Professional installation is recommended to ensure correct camera compatibility, PoE load planning, HDD installation, network setup, remote viewing configuration, recording schedules, and AcuSense event setup. Hard drives are usually sold separately unless included by the supplier.

Compression and Recording
