Hikvision DS-PDSMK-E-WE AX PRO Wireless Smoke Detector
Short Description
The Hikvision DS-PDSMK-E-WE is a wireless photoelectric smoke detector designed for Hikvision AX PRO alarm systems. Featuring a high-quality smoke detection chamber, built-in 85 dB siren, red LED alarm indication, 868 MHz wireless communication, and long battery life, it provides reliable 24/7 fire detection for homes, offices, retail stores, and commercial spaces.
Product Description
Protect your property against fire hazards with the Hikvision DS-PDSMK-E-WE AX PRO Wireless Smoke Detector. Designed for indoor fire safety applications, this detector uses a photoelectric smoke-sensing chamber to detect smoke particles quickly and accurately, helping provide early warning in the event of a fire.
The DS-PDSMK-E-WE supports both independent operation and wireless reporting to a compatible Hikvision AX PRO alarm system. When smoke is detected, the built-in siren delivers a loud audible alert of at least 85 dB at 3 metres, while the red LED indicator provides clear visual alarm notification.
Using secure 868 MHz wireless transmission, the detector communicates with the AX PRO system over a long RF range of up to 1,600 metres in open space. This allows flexible installation without the need for signal wiring, making it suitable for residential and commercial environments.
With a replaceable CR123A battery, compact ceiling-mount design, and EN 14604 certification, the Hikvision DS-PDSMK-E-WE is a dependable smoke detection solution for modern wireless alarm installations.
Key Features:
-
Wireless smoke detector for Hikvision AX PRO systems
-
Photoelectric smoke-sensing chamber
-
Detects smoke for early fire warning
-
Supports independent operation and wireless reporting
-
Built-in siren rated at ≥85 dB at 3 m
-
Red LED alarm indicator
-
868 MHz wireless transmission
-
RF range up to 1,600 m in open space
-
Battery-powered for flexible installation
-
Replaceable CR123A 3 V battery
-
Long battery lifespan of up to 10 years
-
Test / hush button functionality
-
Signal strength test support
-
Indoor ceiling-mount installation
-
EN 14604 certified
-
Compact white design suitable for modern interiors
Technical Specifications
Brand: Hikvision
Model: DS-PDSMK-E-WE
Product Type: AX PRO Wireless Smoke Detector
Detection Method: Photoelectric smoke chamber
Application: Indoor
Operating Mode: Independent and wireless reporting
Siren Volume: ≥85 dB at 3 m
LED Indicator: Red alarm LED
Transmission Frequency: 868 MHz
RF Range: Up to 1,600 m in open space
Battery Type: 1 × CR123A, 3 V
Battery: Replaceable
Battery Life: Up to 10 years
Operating Temperature: -10°C to 50°C
Certified Operating Temperature: 0°C to 49°C
Storage Temperature: -20°C to 60°C
Operating Humidity: 5% to 90%
Dimensions: Ø120 mm × 48 mm
Installation Method: Ceiling mount
Certification: EN 14604:2005 + AC:2008
Compatibility: Hikvision AX PRO wireless alarm systems
What’s in the Box:
Ideal For:
-
Homes and apartments
-
Offices and boardrooms
-
Retail stores
-
Storerooms and stock rooms
-
Reception areas
-
Corridors and passages
-
Commercial fire safety applications
-
Hikvision AX PRO alarm system installations
