DS-1LN6UTC0
Hikvision DS-1LN6UTC0 Cat6 U/UTP Network Cable – 305m
The Hikvision DS-1LN6UTC0 is a high-quality Cat6 network cable designed for reliable data transmission in CCTV, IP camera, networking, access control, and general structured cabling installations. Supplied in a 305m pull box, it is ideal for professional installers working on homes, offices, warehouses, retail stores, commercial buildings, and security projects.
Built with solid bare copper conductors, the DS-1LN6UTC0 offers stable signal performance, low resistance, and reliable connectivity across network devices. It is suitable for connecting IP cameras, NVRs, switches, routers, access points, intercoms, and other Ethernet-based equipment.
The cable supports Cat6 performance over the 1.0MHz to 250.0MHz frequency range, with a characteristic impedance of 100 ± 15Ω and delay skew of ≤45ns/100m. Its solid copper construction and 57V operating voltage rating make it suitable for many standard network and PoE-based security applications, depending on the connected equipment and installation requirements.
The cable features a durable PVC sheath, rip-cord, and internal separator for easier installation and improved cable structure. With an operating temperature range of -20°C to 75°C, it is built for dependable indoor network cabling projects.
Key Features
-
Cat6 U/UTP network cable
-
Model: DS-1LN6UTC0
-
305m cable length
-
Solid bare copper conductor
-
99.95% copper material
-
24AWG conductor size
-
0.515mm conductor diameter
-
PVC outer sheath
-
HDPE insulation
-
Internal separator
-
Rip-cord included
-
Stable electrical performance
-
Suitable for IP CCTV and data networking
-
Compliant with ISO/IEC 11801
-
Compliant with ANSI/TIA-568.2-D
-
RoHS 2.0 compliant
-
57V operating voltage
-
Suitable for professional structured cabling installations
-
- Stable electrical performance, compliant with ANSI/TIA-568.2-D, IEC 61156, ISO/IEC 11801.
- Compliant with RoHS 2.0.
- Sheath with strong mechanical properties, and high tensile and compressive strength, reducing damage during the project.
- Excellent performance in the Fluke 90-meter permanent link test while working continuously at 50°C high temperature.
- Excellent performance in the Fluke 100-meter channel test while being continuously loaded with 57 V/1 A DC power (PoE).
- Solid-Bare Copper conductor with less resistance, and better electrical properties and transmission performance.
Ideal For
-
IP CCTV camera installations
-
NVR and network switch connections
-
PoE camera cabling
-
Access control systems
-
Intercom systems
-
Office network points
-
Home network installations
-
Retail and commercial cabling
-
Warehouses and business premises
-
Structured Ethernet cabling projects
Technical Specifications
-
Brand: Hikvision
-
Model: DS-1LN6UTC0 (Grey)
-
Product Type: Cat6 U/UTP Network Cable
-
Cable Category: Cat.6
-
Cable Length: 305 ± 1.5m
-
Conductor Material: Solid bare copper, 99.95%
-
Conductor Diameter: 0.515 ± 0.01mm
-
Wire Gauge: 24AWG
-
Insulation Material: HDPE
-
Insulation Diameter: 0.93 ± 0.05mm
-
Sheath Material: PVC
-
Sheath Diameter: 5.5 ± 0.40mm
-
Sheath Thickness: 0.5 ± 0.05mm
-
Cable Colour: Grey or orange, depending on variant
-
Rip-Cord: Yes
-
Separator: Yes
-
Impedance: 100 ± 15Ω
-
Frequency Range: 1.0MHz to 250.0MHz
-
Delay Skew: ≤45ns/100m
-
DC Resistance: ≤9.38Ω/100m
-
DC Conductor Resistance Unbalance: ≤4.0%
-
Operating Voltage: 57V
-
Ambient Temperature: -20°C to 75°C
-
Package Dimensions: 390 × 390 × 210mm
-
Fire Resistance: CPR Fca
Why Choose the Hikvision DS-1LN6UTC0?
The Hikvision DS-1LN6UTC0 is a dependable choice for installers who need a proper Cat6 copper network cable for security and data installations. Its solid bare copper conductors, Cat6 performance, PVC sheath, 305m pull-box length, and recognised cabling standard compliance make it suitable for professional IP CCTV and networking projects.
Installation Note
Professional installation is recommended to ensure correct cable routing, termination, bend radius, testing, labelling, and compatibility with network switches, PoE devices, patch panels, and connected equipment.
